Alpine Status Esoteric 11-Inch (28cm) Subwoofer

Features

• AlpineF#1Status speaker trickle-down technology
• Maximum Peak Power Handling: 1200 Watts
• Maximum RMS Power Handling: 400 Watts
• Aluminum die-cast frame
• Backed carbon fiber cone
• Double-gathered edge
• Heavy-gauge screw-type cable terminals
• High-performance ferrite magnet

Thiele / Small Parameters

• Re: 6.03 Ohm
• fs: 30.8 Hz
• Mms: 387.143 g
• Rms: 12.368 kg/s
• Cms: 0.069 mm/N
• BI: 29.491 N/A
• Qms: 6,048
• Qes: 0,519
• Qts: 0,478
• Vas: 48.9213 l
• Sd: 706.86 cm2

Specifications

• Impedance: 2 Ohm + 2 Ohm
• Woofer diameter: 279mm
• Cut-out diameter: 251mm
• Mounting depth: 196mm
• Sensitivity 84dB SPL (2.83 V x2 @ 1 m)
• Frequency Response: 25Hz – 300Hz
• Recommended amplification: up to 200W / 2 Ohm RMS per channel

Recommended Enclosure Specifications

Sealed Enclosure

Volume: 32 Litre

Ported Enclosure

Volume: 40 Litre

Port Diameter: 100mm

Port Length: 500mm
